RXi1500e

Expanded, enclosed rotary storage with 1,500 kg capacity — the productivity powerhouse, scaled up.

Made in North America

Key Features

The RXi1500e pairs the enclosed-shuttle RXi-e platform with the heavier capacity of the 1500 Series, handling payloads to 1,500 kg above the pallet and pallets in the 600–800 mm range across five staged stations. Built for single-machine cells running larger parts unattended for extended periods, it offers the deep staging and enclosed operation of the RXi1000e at greater capacity. The MT+ operator-access option is available on this model.

Technical Data

Max payload (above pallet)	1,500 kg
Machines enslaved	1
Storage capacity	8-20 pallets
Pallet size	600-900 mm
Max part diameter	1200 mm
Carrier arm extension	1.2 m
Changeover time	< 180 seconds
Dimensions (L × W × H)	See Layout Drawings below
Control software	Siemens Sinamics S210
Options	MT+ operator access

Configurations vary based on pallet storage, shelving, system layout, and facility requirements.

Every Uni-Fab Automation pallet changer is powered by PalletOS — the intuitive software platform built to help operators control, manage, and scale automation with confidence.

Learn More

Available on the RXi-e series

MT+ Operator Access

Safe, direct operator access between the pallet changer and the CNC — without taking the system offline.

MT+ replaces the standard single-machine stationary base with a linear rail system and a set of doors on the pallet changer. Using safety-lock doors, the operator requests access; the shuttle and pallet-pool doors retreat to open a protected work zone directly in front of the CNC, while the shuttle continues to operate inside its fully enclosed area. When the operator exits and locks the MT+ zone, the shuttle doors reopen and the shuttle resumes full access to the CNC. The result is hands-on access exactly when it’s needed — for setup, inspection, or first-article checks — with no compromise to operator safety and no interruption to the shuttle’s continuous operation.
