RXi1500
The compact rotary platform of the RXi1000, scaled up for heavier parts — 1,500 kg capacity in a five-station pool.
Made in North America
Key Features
The RXi1500 takes the proven RXi1000 rotary platform and scales it for heavier work, supporting payloads up to 1,500 kg above the pallet and larger pallets in the 600–800 mm range. A five-station rotary pool keeps the next jobs staged and the spindle cutting, making it the right choice for single-machine cells producing larger, denser parts that still demand continuous, hands-off throughput.
Technical Data
| Max payload (above pallet) | 1,500 kg |
| Machines enslaved | 1 |
| Storage capacity | 5 stations |
| Pallet size | 600-800 mm |
| Max part diameter | 1200 mm |
| Carrier arm extension | 1.2 m |
| Changeover time | < 60 sec. |
| Dimensions (L × W × H) | See Layout Drawings below |
| Control software | Siemens Sinamics S210 |
Configurations vary based on pallet storage, shelving, system layout, and facility requirements.
Every Uni-Fab Automation pallet changer is powered by PalletOS — the intuitive software platform built to help operators control, manage, and scale automation with confidence.
Learn MoreLayout Drawings
