RXi1000

Compact rotary automation that keeps every load station within reach — maximum uptime in a minimal footprint.

Made in North America

Key Features

The RXi1000 packs six load stations on 360° turntables into a compact rotary pallet pool, giving operators fast, ergonomic access to every station while conserving valuable floor space. Built for single-machine cells running frequent changeovers, it keeps the spindle cutting by staging the next job while the current one runs — ideal for shops that want continuous, unattended production without dedicating a large footprint to automation.

Technical Data

Max payload (above pallet)	1,000 kg
Machines enslaved	1
Storage capacity	6 stations
Pallet size	400-550 mm
Max part diameter	800 mm
Carrier arm extension	1.2 m
Changeover time	< 60 sec.
Dimensions (L × W × H)	See Layout Drawings below
Control software	Siemens Sinamics S210

Configurations vary based on pallet storage, shelving, system layout, and facility requirements.

Every Uni-Fab Automation pallet changer is powered by PalletOS — the intuitive software platform built to help operators control, manage, and scale automation with confidence.

Learn More
