MXi250

The 250 Series in a linear, multi-machine layout — sub-30-second changeovers across your cell.

Made in North America

Key Features

The MXi250 brings the new 250 Series dual-shuttle architecture to Uni-Fab Automation's linear platform. Like the RXi250e, it keeps a ready pallet staged on the shuttle at all times, cutting the spindle downtime caused by traditional drop-off-then-retrieve cycles and completing changeovers in under 30 seconds. Built for high-production, high-capacity parts, it pairs the speed of the 250 Series with the linear scalability of the MXi family for multi-machine cells.

Technical Data

Max payload (above pallet)	1,050 kg
Machines enslaved	1 to 8
Storage capacity	10-200
Pallet size	200x200 to 450x450 mm
Max part diameter	800 mm
Carrier arm extension	1.7 m
Shuttle design	Dual-pallet shuttle (ready pallet always staged)
Changeover time	< 30 seconds
Dimensions (L × W × H)	Dependent on machine layout
Control software	Siemens Sinamics S210

Configurations vary based on pallet storage, shelving, system layout, and facility requirements.

Every Uni-Fab Automation pallet changer is powered by PalletOS — the intuitive software platform built to help operators control, manage, and scale automation with confidence.
